Product Details
＋
| Product Attribute | Attribute Value |
|---|---|
| Alternate Mfr Part Number | VAL-MS-T1/T2 175/12.5/1 1-FM |
| Approvals | KEMA-KEUR, ÖVE, IECEE CB Scheme, CCA, UL Recognized, cUL Recognized, EAC, DNV GL, cULus Recognized |
| Color | Jet Black Ral 9005 |
| Connection Type | Plug-in/screw connection via COMBICON |
| Depth | 77.5 mm (incl. DIN rail 7.5 mm) |
| Height | 96.8 mm |
| Housing Material | PBT |
| IP Rating | IP20 |
| Mounting Type | DIN rail: 35 mm |
| Screw Type | M2 |
| Standards | EN 61643-11 2012 |
| Stripping Length | 7 mm |
| Type | DIN rail module, two-section, divisible |
| UPC Code | 4046356624336 |
| Width | 35.6 mm |
